Hydraulic motor MS 315 SL 6-tooth 34.85mm shaft, ALSG3-315-R4-WOM-01 Ambr
295,00 € excl. VAT
ALSG3-315-R4-WOM-01 21013319
Out of stock
ALSG3-315-R4-WOM-01 21013319
Enter your email address and we will notify you as soon as the item is available.
Free delivery
for orders from €100
Product returns
within 30 business days
Fast pickup
in store
Have questions? Didn’t find the product?
Not sure if the product is suitable? Want to receive an offer? Submit an inquiry to us and we will reply within 1–2 business days.
Product information
Description
Specification
| Type: ALSG3 315 |
| Geometric displacement: 311 cm³/rev |
| Max speed (continuous): 240 rpm |
| Max speed (intermittent): 280 rpm |
| Max torque (continuous): 880 Nm |
| Max torque (intermittent): 960 Nm |
| Max output power (continuous): 20.2 kW |
| Max output power (intermittent): 11 kW |
| Max pressure drop (continuous): 20 MPa |
| Max pressure drop (intermittent): 22.5 MPa |
| Max pressure drop (peak): 26 MPa |
| Max oil flow (continuous): 75 l/min |
| Max oil flow (intermittent): 90 l/min |
| Max inlet pressure (continuous): 25 bar |
| Max inlet pressure (intermittent): 30 bar |
| Weight: 12.3 kg |
Additional information
| Flange | 82.5mm, 106.4mm, 4 bolts |
|---|---|
| Manufacturer | Amberline Hydraulics |
| Connections | BSP 1/2” |
| Connection side/rear | Side |
| Type | Orbital (Gerotor) |
| Volume | 315 |
| Shaft | 6 teeth, 34.85mm |
