Hydraulic motor MS 250 C 32mm shaft, BM3Y-250
307,00 € excl. VAT
EPMS250 BM3Y-250
Out of stock
EPMS250 BM3Y-250
Enter your email address and we will notify you as soon as the item is available.
Free delivery
for orders from €100
Product returns
within 30 business days
Fast pickup
in store
Have questions? Didn’t find the product?
Not sure if the product is suitable? Want to receive an offer? Submit an inquiry to us and we will reply within 1–2 business days.
Product information
Description
Specification
(BM3 / OMS 250 class)
Data:
Displacement: 252.6 cm³/rev
Pressure drop (Δp):
– Continuous: 12.5 MPa (125 bar)
– Intermittent: 16 MPa (160 bar)
– Peak: 20 MPa (200 bar)
Torque:
– Continuous: 440 Nm
– Intermittent: 580 Nm
– Peak: 700 Nm
Speed range (continuous): 6–300 rpm
Max. oil flow: 75 l/min
Max. output power (continuous): 11 kW
Weight: 11.6 kg
Additional information
| Flange | 82.5mm, 106.4mm, 4 bolts |
|---|---|
| Manufacturer | ziHYD |
| Connections | BSP 1/2” |
| Connection side/rear | Side |
| Type | Orbital (Gerotor) |
| Volume | 250 |
| Shaft | 32mm |
