Hydraulic motor MS 160 C 32mm shaft, SAE-A MC2160AC16AG020001300000 with MR flange

Description

Specification

Model code: MC2160AC16AG0200013000000ABAAB

Motor series: XL2 Series

Valve system: Disc valve with valve drive

Orbital gearwheel set type: Geroler

Motor size: 160

Geometric displacement: 157.7 cm³/rev (9.62 in³/rev)

Motor type: Standard

Motor function: Standard

Mounting flange type: 2 Bolt – A (SAE A)

Mounting flange dimensions: Pilot Ø 82.6 × 6.3 mm; bolt circle Ø 106.4 mm; hole Ø 13.6 mm (3.25 × 0.25 in; 4.19 in; 0.54 in)

Shaft type: Straight

Shaft dimension: Ø 32 mm, M8 × 1.25-6H thread in shaft end

Shaft key: Rectangular, 10 × 8 × 45 mm

Main port thread type: BSP

Main port style: Sideport – staggered

Main port dimension: G 1/2

Drain port dimension: G 1/4

Brake release port dimension: n/a

Painted: Yes

Paint information: Painted, Black

Special features assembly: Standard

Dust seal: Standard

Shaft seal: HNBR – High pressure

Seal kit: Z331-51

Front bearing type: Tapered roller bearing

Rear bearing type: Tapered roller bearing

Orbital gearwheel set: Standard

Check valve function: Yes

Hydraulic valve function: None

Sensor: None

Packaging: Single pack

Name tag: Danfoss name tag

Design code: 2

Brand: DANFOSS

Product height: 108.712 mm (4.280 in)

Product length: 186.944 mm (7.360 in)

Product width: 131.318 mm (5.170 in)
