Hydraulic motor MS 160 C 32mm shaft, ALSG3-160-R4-C32-01 Ambr
245,00 € excl. VAT
ALSG3-160-R4-C32-01 21003346
2 in stock
ALSG3-160-R4-C32-01 21003346
Product information
Description
Specification
Type: ALSG3 160
Displacement: 154 cm³/rev
Max speed (continuous): 470 rpm
Max speed (intermittent): 560 rpm
Max torque (continuous): 365 Nm
Max torque (intermittent): 540 Nm
Max torque (peak): 560 Nm
Max output power (continuous): 18.1 kW
Max output power (intermittent): 25 kW
Max pressure drop (continuous): 21 MPa
Max pressure drop (intermittent): 22.5 MPa
Max pressure drop (peak): 28 MPa
Max oil flow (continuous): 75 l/min
Max oil flow (intermittent): 90 l/min
Max inlet flow (continuous): 25 l/min
Max inlet flow (intermittent): 30 l/min
Weight: 10.7 kg
Additional information
| Flange | 82.5mm, 106.4mm, 4 varžtai |
|---|---|
| Manufacturer | Amberline Hydraulics |
| Connections | BSP 1/2” |
| Connection side/rear | Šonas |
| Type | Orbitinis (Gerotorinis) |
| Volume | 160 |
| Shaft | 32mm |
