Hydraulic motor MS 125 C 32mm shaft, MC2130AH16AG020001000000 EATON

Description

Specification

Model code: MC2130AH16AG0200010000000ABAAB

Motor series: XL2 Series

Valve system: Disc valve with valve drive

Orbital gearwheel set type: Geroler

Motor size: 130

Geometric displacement: 130.5 cm³/rev [7.96 in³/rev]

Motor type: Standard

Motor function: Standard

Mounting flange type: 4 bolt – square

Mounting flange dimensions: Pilot Ø 82.6 × 6.3 mm; bolt circle Ø 106.4 mm; hole Ø 13.6 mm [3.25 × 0.25; 4.19; 0.54 in]

Shaft type: Straight

Shaft dimensions: Ø 32 mm, M8 × 1.25–6H thread in shaft end

Shaft key: Rectangular, 10 × 8 × 45 mm

Main port thread type: BSP

Main port style: Side port – staggered

Main port dimension: G 1/2

Drain port dimension: G 1/4

Brake release port: n/a

Painted: Yes

Paint information: Painted, black

Special features assembly: Standard

Dust seal: Standard

Shaft seal: NBR – standard

Seal kit: Z331-02

Front bearing type: Tapered roller bearing

Rear bearing type: Tapered roller bearing

Orbital gearwheel set: Standard

Check valve function: Yes

Hydraulic valve function: None

Sensor: None

Packaging: Single pack

Name tag: Danfoss

Design code: 2

Brand: DANFOSS

Product height: 108.712 mm [4.280 in]

Product length: 186.944 mm [7.360 in]

Product width: 108.712 mm [4.280 in]
