Hydraulic motor MS 080 C 32mm shaft
Original price was: 332,00 €.235,00 €Current price is: 235,00 €. excl. VAT
SMS80A432YGP
Out of stock
SMS80A432YGP
Enter your email address and we will notify you as soon as the item is available.
Free delivery
for orders from €100
Product returns
within 30 business days
Fast pickup
in store
Have questions? Didn’t find the product?
Not sure if the product is suitable? Want to receive an offer? Submit an inquiry to us and we will reply within 1–2 business days.
Product information
Description
Motor type: Orbital motor
Displacement: 80 cm³/rev
Flange shape: Square
Flange standard: SAE-A
Number of mounting holes: 4
Shaft type: Straight parallel
Shaft diameter: Ø32 mm
Maximum continuous torque: 194 Nm
Maximum continuous working pressure: 175 bar
Additional information
| Flange | 82.5mm, 106.4mm, 4 bolts |
|---|---|
| Manufacturer | gopart |
| Connections | BSP 1/2” |
| Connection side/rear | Side |
| Type | Orbital (Gerotor) |
| Volume | 80 |
| Shaft | 32mm |
