Hydraulic motor MS 125 C 32mm shaft, 151F0502
650,00 € excl. VAT
Out of stock
Enter your email address and we will notify you as soon as the item is available.
Free delivery
for orders from €100
Product returns
within 30 business days
Fast pickup
in store
Have questions? Didn’t find the product?
Not sure if the product is suitable? Want to receive an offer? Submit an inquiry to us and we will reply within 1–2 business days.
Product information
Description
Specification
Series: OMS
Drain port style: Standard – motor flange
Dust seal: Standard
Front bearing: Tapered roller bearing
Mounting flange: 4 bolt – square
Packaging: Single pack
Port dimensions: G 1/2, G 1/4
Port style: Side ported – offset manifold (2 × M10)
Displacement: 125 cm³/rev
Seal kit: 151F0111
Series name: O-Series
Shaft key: A10 × 8 × 45 mm
Shaft seal: NBR – standard
Shaft size: Ø 32 mm, M8 tap
Shaft style: Straight
Design code: 3
Mounting thread dimensions: Pilot Ø 82.5 × 6.1 mm [3.25 × 0.24]; bolt circle Ø 106.4 mm [4.19]; hole Ø 13.6 mm [0.53]
Additional information
| Flange | 82.5mm, 106.4mm, 4 bolts |
|---|---|
| Manufacturer | White |
| Connections | BSP 1/2” |
| Connection side/rear | Side |
| Type | Orbital (Gerotor) |
| Volume | 125 |
| Shaft | 32mm |
