UNI-3 022 l/min gear pump anti-clockwise KZL 290 bar
285,00 € excl. VAT
G30022UF411
1 in stock
G30022UF411
Free delivery
for orders from €100
Product returns
within 30 business days
Fast pickup
in store
Have questions? Didn’t find the product?
Not sure if the product is suitable? Want to receive an offer? Submit an inquiry to us and we will reply within 1–2 business days.
Product information
Description
UNI-3 gear pump G30022UF411 is a hydraulic gear pump designed for oil supply in mobile and industrial hydraulic systems. Its compact construction and UNI-3 ISO mounting standard allow installation in a wide range of hydraulic applications and machinery.
The pump provides stable oil flow, reliable high-pressure operation, and long service life.
Application:
- Mobile hydraulics
- Tipping systems
- Agricultural machinery
- Construction equipment
- Hydraulic power units
Technical specifications:
- Type: hydraulic gear pump
- Series: UNI-3 / ISO
- Model: G30022UF411
- Displacement: 22 cm³/rev
- Flow rate: ~22 l/min (depending on RPM)
- Max continuous pressure: 290 bar
- Max intermittent pressure: 315 bar
- Max peak pressure: 325 bar
- Max continuous speed: 2500 rpm
- Max intermittent speed: 3000 rpm
- Inlet port: G1/2″
- Outlet port: G3/4″
- Shaft: 6×21×25 UNI 8953
- Max torque: 360 Nm
- Mounting standard: UNI-3 ISO
Additional information
| Group | UNI |
|---|---|
| Direction | Kairinis |
| Inlet | BSP 3/4” |
| Outlet | BSP 1/2” |
| Connections | Sriegis |
| Connection side/rear | Galas/Šonas |
| Front cover | 21 UNI 222 |
| Pressure | 290bar |
| Volume | 22 |
| Shaft | 6x21x25 6 dantų 21 UNI222 (DIN 5463) |
| Single / Tandem | Viengubas |
