Rotator CPR14
3200,00 € excl. VAT
CPR rotators are ideal for working conditions where flat-body rotator models and high torque is required.
Out of stock
CPR rotators are ideal for working conditions where flat-body rotator models and high torque is required.
Product information
Description
The Baltrotors CPR14 is a heavy-duty hydraulic rotator designed for grapples, material handlers, forestry equipment, sorting grabs, and other hydraulic attachments requiring continuous rotation. The unit features a robust design, unlimited rotation capability, and high load capacity for demanding industrial applications.
The CPR14 is equipped with integrated relief valves and internal oil passages for grapple or tool operation. It can be used in both rigid-mounted applications and systems connected via a link.
Technical Data
- Manufacturer: Baltrotors
- Model: CPR14
- Type: Hydraulic rotator
- Rotation: Unlimited
- Rated displacement: 1222 cm³/rev
- Torque at 25 MPa: 4500 Nm
- Maximum axial load: 140 kN
- Maximum radial load: 100 kN
- Moment of deflection: 40 kNm
- Maximum rotation speed: 25 rpm
- Grapple oil duct area: 260 mm²
- Weight: 160 kg
Hydraulic Connections
Rotation (R):
- Maximum working pressure: 25 MPa (250 bar)
- Recommended oil flow: 35 l/min
- Connection: G1/2
Grapple/Tool Open (GO):
- Maximum working pressure: 35 MPa (350 bar)
- Connection: G3/4
Grapple/Tool Close (GC):
- Maximum working pressure: 35 MPa (350 bar)
- Connection: G3/4
