Proportional hydraulic distributor for front loaders (LS) 2 sec. max flow 90L. 1-floatin
2350,00 € excl. VAT
ROZ90L/2L-EHP-OP
Out of stock
ROZ90L/2L-EHP-OP
Enter your email address and we will notify you as soon as the item is available.
Free delivery
for orders from €100
Product returns
within 30 business days
Fast pickup
in store
Have questions? Didn’t find the product?
Not sure if the product is suitable? Want to receive an offer? Submit an inquiry to us and we will reply within 1–2 business days.
Product information
Description
This is a 2-section hydraulic control valve designed for controlling hydraulic functions of front loaders using electric proportional control. It is used in front loaders to operate hydraulic cylinders (lifting, bucket), ensuring precise and smooth movement control via an electrical signal.
Technical data:
- Nominal flow: 90 l/min
- Maximum working pressure: 250 bar
- Power supply: 12 V DC
- Ambient temperature: -30°C to +50°C
- Oil temperature: up to +85°C
- Recommended oil viscosity: 12–75 cSt
- Max. oil contamination: Class 9 (NAS 1638 / ISO 4406)
-
Connections (BSP):
- P1–P2–T1: G1/2″
- A/B: G1/2″
- T2: G3/4″
- LS (TCO): G3/4″
