Low pressure valve 2/2 G1/8 NC 24VDC 0-13bar
42,00 € excl. VAT
SLP06-030E
1 in stock
SLP06-030E
Free delivery
for orders from €100
Product returns
within 30 business days
Fast pickup
in store
Have questions? Didn’t find the product?
Not sure if the product is suitable? Want to receive an offer? Submit an inquiry to us and we will reply within 1–2 business days.
Product information
Description
SLP 2/2 is a normally closed solenoid-operated diaphragm valve designed for electrically controlling the flow of liquids and gases. The NC (Normally Closed) configuration keeps the valve closed when de-energized and opens the flow path when the 24 VDC coil is energized.
The valve features G1/8″ threaded ports and a 3 mm orifice. The operating pressure range is 0–13 bar, making it suitable for low-pressure automation, pneumatic and fluid control systems.
The brass valve body and solenoid actuator provide a compact 2/2 flow-control solution. SLP-series valves can be used with air, gas, water, light oil and other media compatible with the selected sealing material.
Technical Data
- Manufacturer: E·MC
- Series: SLP
- Type: 2/2 solenoid-operated diaphragm valve
- Operation: NC – Normally Closed
- Port size: G1/8″
- Orifice: Ø3 mm
- Supply voltage: 24 VDC
- Operating pressure: 0–13 bar
- Body material: Brass
