Hydraulic motor MV 800 SH 16-tooth shaft

Description

Specification

Motor size: 800

Geometric displacement: 801.8 cm³/rev

Maximum speed (continuous): 250 rpm

Maximum speed (intermittent): 300 rpm

Maximum torque (continuous): 1880 Nm

Maximum torque (intermittent): 2110 Nm

Maximum output power (continuous): 42.5 kW

Maximum output power (intermittent): 48.0 kW

Maximum pressure drop (continuous): 160 bar

Maximum pressure drop (intermittent): 180 bar

Maximum pressure drop (peak): 210 bar

Maximum oil flow (continuous): 200 l/min

Maximum oil flow (intermittent): 240 l/min

Maximum starting pressure with unloaded shaft: 8 bar

Minimum starting torque at max. pressure drop (continuous): 1510 Nm

Minimum starting torque at max. pressure drop (intermittent): 1700 Nm
