Hydraulic motor MV 630 C 50mm shaft

Description

Specification

Motor size: 630

Geometric displacement: 629.1 cm³/rev

Maximum speed (continuous): 315 rpm

Maximum speed (intermittent): 380 rpm

Maximum torque (continuous): 1660 Nm

Maximum torque (intermittent): 1940 Nm

Maximum torque (peak): 2210 Nm

Maximum output power (continuous): 48.0 kW

Maximum output power (intermittent): 56.0 kW

Maximum pressure drop (continuous): 180 bar

Maximum pressure drop (intermittent): 210 bar

Maximum pressure drop (peak): 240 bar

Maximum oil flow (continuous): 200 l/min

Maximum oil flow (intermittent): 240 l/min

Maximum inlet pressure (continuous): 210 bar

Maximum inlet pressure (intermittent): 250 bar

Maximum inlet pressure (peak): 300 bar

Maximum return pressure without drain line (0–100 rpm): 60 bar

Maximum return pressure without drain line (100–300 rpm): 30 bar

Maximum return pressure without drain line (>300 rpm): 20 bar

Maximum return pressure in drain line (up to max. rpm): 75 bar

Maximum return pressure with drain line (continuous): 140 bar

Maximum return pressure with drain line (intermittent): 175 bar

Maximum return pressure with drain line (peak): 210 bar

Maximum starting pressure with unloaded shaft: 8 bar

Minimum starting torque at max. pressure drop (continuous): 1330 Nm

Minimum starting torque at max. pressure drop (intermittent): 1550 Nm

Minimum speed: 6 rpm

Weight (EPMV): 34.9 kg

Weight (EPMVW): 35.5 kg

Weight (EPMVS): 25.6 kg
