Hydraulic motor MV 400 C 50mm shaft, 151B3101

Description

Specification

Model code: OMV-0400-A-NN-G34-AE-1E-A35-A-A-1B-1-N-NN-NNNNN-NN-NN-NN-SP-NNN

Motor series: OMV Series

Motor size: 400

Geometric displacement: 400.9 cm³/rev

Motor type: standard

Motor function: standard

Valve system: disc valve with valve drive

Orbital gearwheel set: standard

Orbital gearwheel set type: Geroler

Mounting flange type: 4-bolt – square

Mounting flange dimensions: pilot dia. 160.0 × 11.0 mm, bolt circle dia. 200.0 mm, hole dia. 18.0 mm

Shaft type: straight

Shaft dimensions: dia. 50 mm, M12 × 1.75–6H thread in shaft end

Shaft key: rectangular key, A14 × 9 × 70 mm, DIN 6885

Shaft seal: NBR – standard

Main port thread type: BSP

Main port style: side ported – staggered

Main port dimensions: G 1, 4 × M12 block mounting threads

Drain port dimension: G 1/4

Brake release port: n/a

Front bearing type: tapered roller bearing

Rear bearing type: tapered roller bearing

Dust seal: standard

Check valve function: yes

Hydraulic valve function: none

Sensor: none

Painted: no

Paint information: n/a

Special features – assembly: standard

Packaging: single pack

Name tag: Danfoss name tag

Seal kit: 151B0129

Design code: 2

Overall dimensions: 23.6 × 44.4 × 22.2 cm
