Hydraulic motor MR 250 C 25mm shaft, MCS245 AA 02 AA110020A000C0
206,00 € excl. VAT
MCS245AA02AA110020A000C0 MR250 OMR250 SMR250 BMR250 GMR250 EPRM250 151-0247
Out of stock
MCS245AA02AA110020A000C0 MR250 OMR250 SMR250 BMR250 GMR250 EPRM250 151-0247
Enter your email address and we will notify you as soon as the item is available.
Free delivery
for orders from €100
Product returns
within 30 business days
Fast pickup
in store
Have questions? Didn’t find the product?
Not sure if the product is suitable? Want to receive an offer? Submit an inquiry to us and we will reply within 1–2 business days.
Product information
Description
| Specification |
|---|
| Model code: MCS245AA02AA110020A000C00B |
| Motor series: XLS Series |
| Valve system: Spool valve |
| Orbital gearwheel set type: Geroler |
| Motor size: 245 |
| Geometric displacement: 243.9 cm³/rev [14.88 in³/rev] |
| Motor type: Standard |
| Motor function: Standard |
| Mounting flange type: 2-bolt – A |
| Mounting flange dimensions: 82.6 × 5.0 mm (pilot dia × height), bolt circle dia 106.4 mm, hole 13.5 mm [3.25 × 0.20 in, 4.19 in, 0.53 in] |
| Shaft type: Straight |
| Shaft dimensions: Diameter 25 mm, M8 thread in shaft end (special component) |
| Shaft key: Rectangular key A8 × 7 × 32 mm |
| Main port thread type: BSP |
| Main port style: Side port – staggered |
| Main port dimensions: G 1/2, 4 × M8 block mounting threads |
| Drain port dimensions: G 1/4 |
| Brake release port dimensions: N/A |
| Painted: Yes |
| Paint information: Painted, black |
| Special features assembly: Standard |
| Dust seal: Standard |
| Shaft seal: NBR – high pressure |
| Seal kit: Z331-59 |
| Front bearing type: Journal bearing |
| Rear bearing type: Journal bearing |
| Orbital gearwheel set: Standard |
| Check valve function: Yes |
| Hydraulic valve function: None |
| Sensor: None |
| Packaging: No data available |
| Name tag: Danfoss name tag |
| Design code: 2 |
| Product height: 3.700 in / 93.980 mm |
| Product length: 7.200 in / 182.880 mm |
| Product width: 5.120 in / 130.048 mm |
Additional information
| Flange | 82.5mm 106.4mm, 2 bolts |
|---|---|
| Manufacturer | Eaton Char-Lynn |
| Connections | BSP 1/2” |
| Connection side/rear | Side |
| Type | Orbital (Gerotor) |
| Volume | 250 |
| Shaft | 25mm |
