Hydraulic motor MR 100 SHD ziHYD BMRY-100 H3
Original price was: 165,00 €.126,00 €Current price is: 126,00 €. excl. VAT
EPRM100SH MR100SH OMR100SH OMRX100SH
Out of stock
EPRM100SH MR100SH OMR100SH OMRX100SH
Enter your email address and we will notify you as soon as the item is available.
Free delivery
for orders from €100
Product returns
within 30 business days
Fast pickup
in store
Have questions? Didn’t find the product?
Not sure if the product is suitable? Want to receive an offer? Submit an inquiry to us and we will reply within 1–2 business days.
Product information
Description
| Specification |
|---|
| Type: BMR-100 |
| Displacement: 100.5 ml/rev |
| Max. pressure drop (continuous): 14 MPa |
| Max. pressure drop (intermittent): 17.5 MPa |
| Max. pressure peak: 20 MPa |
| Max. torque (continuous): 194 Nm |
| Max. torque (intermittent): 236 Nm |
| Max. torque peak: 270 Nm |
| Continuous speed range: 10–600 rpm |
| Max. flow (continuous): 60 l/min |
| Max. output power (continuous): 10 kW |
| Weight: 7.0 kg |
Additional information
| Flange | 82.5mm 106.4mm, 2 bolts |
|---|---|
| Manufacturer | ziHYD |
| Connections | BSP 1/2” |
| Connection side/rear | Side |
| Type | Orbital (Gerotor) |
| Volume | 100 |
| Shaft | 6 teeth, 25.4mm |
