Hydraulic motor MR 100 C 25mm shaft, ALSG2-L-100-O2-C25-01 Ambr
150,00 € excl. VAT
ALSG2-L-100-O2-C25-01 21003295
Out of stock
ALSG2-L-100-O2-C25-01 21003295
Enter your email address and we will notify you as soon as the item is available.
Free delivery
for orders from €100
Product returns
within 30 business days
Fast pickup
in store
Have questions? Didn’t find the product?
Not sure if the product is suitable? Want to receive an offer? Submit an inquiry to us and we will reply within 1–2 business days.
Product information
Description
| Specification |
|---|
| Type: ALSG1 / ALSG1W 100 |
| Geometric displacement: 96.2 cm³/rev |
| Max. speed (continuous): 615 rpm |
| Max. speed (intermittent): 770 rpm |
| Max. torque (continuous): 182 Nm |
| Max. torque (intermittent): 227 Nm |
| Max. torque peak: 264 Nm |
| Max. output power (continuous): 11.0 kW |
| Max. output power (intermittent): 13.0 kW |
| Max. pressure drop (continuous): 14 MPa |
| Max. pressure drop (intermittent): 17.5 MPa |
| Max. pressure peak: 22.5 MPa |
| Max. flow (continuous): 60 l/min |
| Max. flow (intermittent): 75 l/min |
| Weight: 5.9 kg |
Additional information
| Flange | 82.5mm 106.4mm, 2 bolts |
|---|---|
| Manufacturer | Amberline Hydraulics |
| Connections | BSP 1/2” |
| Connection side/rear | Side |
| Type | Orbital (Gerotor) |
| Volume | 100 |
| Shaft | 25mm |
