GR2 19.0 cm3/r gear pump 2XP-A-190-S-EUR-B-N-10-0-N19N13
212,00 € excl. VAT
2XP-A-190-S-EUR-B-N-10-0-N19N13
Out of stock
2XP-A-190-S-EUR-B-N-10-0-N19N13
Enter your email address and we will notify you as soon as the item is available.
Free delivery
for orders from €100
Product returns
within 30 business days
Fast pickup
in store
Have questions? Didn’t find the product?
Not sure if the product is suitable? Want to receive an offer? Submit an inquiry to us and we will reply within 1–2 business days.
Product information
Description
Walvoil 2XP-A-190-S-EUR-B-N-10-0-N19N13 is a Group 2 external gear hydraulic pump with a displacement of 19.8 cm³/rev. It is designed to convert mechanical drive power into hydraulic oil flow for use in hydraulic systems.
The pump has left-hand (CCW) rotation and features a European standard 4-bolt EUR mounting flange. The drive shaft is a 1:8 tapered shaft with key. Side-mounted European flange connections are used for the inlet and outlet; the N19N13 configuration uses an EU40 inlet and EU30 outlet.
Technical Data
- Manufacturer / brand: Walvoil / Galtech
- Model: 2XP-A-190-S-EUR-B-N-10-0-N19N13
- Series: 2XP Xtreme
- Type: Hydraulic gear pump
- Group: 2
- Displacement: 19.8 cm³/rev
- Rotation: Left-hand (CCW)
- Mounting flange: EUR, 4-bolt
- Flange dimensions: 96 × 72 mm
- Pilot diameter: Ø36.5 mm
- Shaft: 1:8 tapered
- Shaft key: 3.2 mm
- Inlet port: EU40, flanged
- Outlet port: EU30, flanged
- Seals: NBR
- Flange and cover material: Aluminium
- Continuous pressure: up to 210 bar
- Intermittent pressure: up to 220 bar
- Maximum pressure: up to 230 bar
Additional information
| Group | Group 2 |
|---|---|
| Direction | Left-hand |
| Inlet | 40mm |
| Outlet | 30mm |
| Connections | Flange Italian / Diamond |
| Connection side/rear | Side |
| Front cover | European |
| Volume | 19.0 |
| Shaft | 1/8 Group 2 tapered |
| Single / Tandem | Single |
