GR2 06.0 cm3/r gear pump 2XP-A-060-D-B80C-B-N-11-0-T20T15
195,00 € excl. VAT
1GP20012651 2XP-A-060-D-B80C-B-N-11-0-T20T15
4 in stock
1GP20012651 2XP-A-060-D-B80C-B-N-11-0-T20T15
Free delivery
for orders from €100
Product returns
within 30 business days
Fast pickup
in store
Have questions? Didn’t find the product?
Not sure if the product is suitable? Want to receive an offer? Submit an inquiry to us and we will reply within 1–2 business days.
Product information
Description
This is an external gear hydraulic pump belonging to the Walvoil 2XP series (Group 2), designed for medium-duty hydraulic systems. It is used to generate oil flow in hydraulic systems and is suitable for mobile and industrial equipment such as tractors, loaders, presses, and hydraulic power units.
Technical data:
- Type: external gear pump
- Series: 2XP (Group 2)
- Displacement: 6.0–6.1 cm³/rev
- Max. working pressure: up to 250 bar
- Max. speed: up to ~4000 rpm
- Rotation: D (right-hand / clockwise)
- Flange: B80C (EU 4-bolt, ~100×72 mm)
- Shaft: tapered (typically 1:5 with M12)
- Ports: side ports
Additional information
| Grupė | Group 2 |
|---|---|
| Kryptis | Right-hand |
| Matmuo įėjimo (įsiurbimo) | 40mm |
| Matmuo išėjimo (slėgiminė) | 35mm |
| Pajungimai | Flange German / Bosch |
| Pajungimai Galas/Šonas | Side |
| Priekinis dangtelis | B80 Bosch |
| Slėgis | 250bar |
| Darbinis tūris, cm³/aps. | 06.0 |
| Velenas | 1/5 Group 2 tapered |
| Viengubas / Dvigubas | Single |
