FL INTERLOCK SFL 60.3 (1-1/2″) 90° fitting for 1-1/4″ hose SAE 3000, M43310-20-24

65,00 € excl. VAT

M43310-20-24

2 in stock

M43310-20-24

SKU: FI601140 Category:
Free delivery
for orders from €100
Product returns
within 30 business days
Fast pickup
in store
Have questions? Didn’t find the product?
Not sure if the product is suitable? Want to receive an offer? Submit an inquiry to us and we will reply within 1–2 business days.

Product information

Specifications

Description

Manuli M43310-20-24 is a straight INTERLOCK hydraulic hose fitting with an SFL / SAE Code 61 (SAE 3000) flange connection. It is designed for DN31 (1 1/4″, -20) hydraulic hose. The flange size is 1 1/2″, with a D dimension of 60.5 mm.

The INTERLOCK design provides a secure connection with compatible high-pressure spiral hydraulic hoses. The flange connection complies with SAE J516 / ISO 12151-3.

Technical Data

  • Manufacturer: Manuli
  • Part number: M43310-20-24
  • Series: INTERLOCK PLUS
  • Fitting type: Straight, 0°
  • Hose size: DN31 / 1 1/4″ / -20
  • Flange type: SFL / SAE Code 61
  • Flange size: 1 1/2″
  • Flange D dimension: 60.5 mm
  • B: 32.1 mm
  • A: 80.0 mm
  • Standard: SAE J516 / ISO 12151-3

Additional information

Antgalio kampas

90

Grupė

INTERLOCK NOZZLE

Sriegio dydis

SFL 60,3 (1’1/2′)

Sriegio tipas

SAE flange

Žarnos dydis

DN31 1-1/4′
